Liftparker

The classic system: Double parking space for convenient parking with pit

The «Liftparker» parking system provides convenient parking on 2 or 3 tiers with pit. Cars parked on the upper tiers can be easily retrieved without removing cars at lower tiers. Off-center pillars increase the comfort when opening car doors. The independent car stacker is an ideal solution for residential and office buildings as well as hotels and houses.

Product variants


Liftparker N4102

Independent parking on 2 tiers with pit. Upper platform with horizontal access and lower platform sloped.



pit depth front / rear

clear height

car height lower tier

car height upper tier

from 170 / 165 cm 295 cm 150 cm 150 cm
to 200 / 195 cm 395 cm 180 cm 150 cm

Liftparker N4202

Independent parking on 2 tiers with horizontal accessible and inclined platforms. Cars with above average height can be easily parked on the upper level by adjusting the inclination degree of the lower platform. A perfect solution for adjusting heights of the parking space after having installed the parking system.



pit depth front / rear

clear height

car height lower tier

car height upper tier

from 170 / 165 cm 295 cm 150 cm 150 cm
to 200 / 195 cm 395 cm 180 cm 150 cm

Liftparker N4402

The conventional parking system for independent parking on 2 —tiers with pit. Appropriate for underground garages with clear heights starting from 325 cm.



pit depth front / rear

clear height

car height lower tier

car height upper tier

from 170 / 165 cm 325 cm 150 cm 150 cm
to 200 / 195 cm 355 cm 180 cm 150 cm

Liftparker N4602

Independent parking on 2 tiers with both platforms horizontal accessible. Appropriate for underground garages with clear heights starting from 325 cm.



pit depth front / rear

clear height

car height lower tier

car height upper tier

from 170 / 165 cm 325 cm 150 cm 150 cm
to 225 / 220 cm 380 cm 205 cm 150 cm

Liftparker N4802

The 2 tier parking system offers additional convenience for getting in and out of the car by providing additional parking space (up to 275 cm wide) and removing pillars on the side.



pit depth front / rear

clear height

car height lower tier

car height upper tier

from 170 / 170 cm 320 cm 150 cm 150 cm
to 220 / 220 cm 350 cm 180 cm 150 cm

Liftparker N4403

Independent parking on 2 tiers with both platforms horizontal accessible. Appropriate for underground garages with clear heights starting from 325 cm.



pit depth front / rear

clear height

car height lower tier

car height upper tier

car height upper tier

from 335 / 330 cm 485 cm 150 cm 150 cm 150 cm
to 385 / 380 cm 545 cm 175 cm 150 cm 150 cm

Features


  • Mechanical car stacker
  • Flexible and adjustable based on project requirements
  • Appropriate for car heights between 150 cm and 240 cm
  • Width of parking space until 275 cm
  • Length of parking space between 500 cm and 520 cm
  • Suitable for a pit depth of at least 165 cm
  • Platform capacity between 2.0 t and 2.6 t
  • Low maintenance and operation costs
  • Independent parking system

Projects


Doubling the number of parking spaces in a building complex in Jerusalem.
